Description
The F 24XR features 18 mic preamp inputs, 16 mono line inputs, 4 stereo line inputs, multi-FX, 6 single control compressors, stereo recording and playback via USB port, balanced main output (Stereo XLR + TRS) . The mono channels are provided with 3-band EQ, with selectable mid frequency, and 3-band for stereo channels. The mixer features 16 PRO DSP internal presets, two stereo output busses and 4 aux sends (2 pre, 1 pre/post, 1 post). It also features 60mm faders.
- Sturdy Metal Chassis
- PRO DSP FX onboard with 16 presets
- Stereo Recording and Playback via USB ports
- Balanced main output audio path from input to output
- 6 single control compressors
- Mono channels provided with 3-band EQ, with selectable mid frequency
- Robust, compact and attractive design.
- Designed and Engineered in Italy
- Internal Universal Power Supply
- 60 mm faders
Electrical specifications
- FREQUENCY RESPONSE: 20 Hz ÷ 20 kHz
- THD+N, 20DB GAIN, 0DBU OUT (% A-WEIGHTED): <0,02% A-Weighted
- POWER SUPPLY: Internal
- VOLTAGE REQUIREMENTS: 100 V – 240 V
- POWER CONSUMPTION (W): 70 W
Inputs
- GAIN RANGE: 0 dB ÷ -50 dB
- GAIN SELECTION: 20 dB ÷ -30 dB
- HI-Z LINE INPUTS IMPEDANCE (MOHM): 1 Mohm
- HI-Z LINE INPUTS: 1
- INPUT NOISE LEVEL (DBU A-WEIGHTED): -124 dBu A-Weighted
- MIC INPUTS IMPEDANCE (KOHM): 14 kohm
- LINE: 16
- LINE INPUT IMPEDANCE (KOHM): 21 kohm
- LOW CUT: 80 Hz
- MIC: 18
- PHANTOM POWER +48V: Yes
- STEREO LINE: 4
- STEREO LINE GAIN SELECTION: 20 dB ÷ -30 dB
- STEREO LINE INPUT IMPEDANCE: 14 kohm
Outputs
- MAIN MIX: 1
- CONTROL ROOM: Yes
- FX SEND: 1
- AUX SEND: 3
- AUX OUTPUT: 4
- GROUP OUT: 2
- PHONES: 1
Outputs specifications
- MAIN OUT LEVEL (DBU): 28 dBu
- AUX OUT LEVEL (DBU): 28 dBu
- GROUP OUT LEVEL (DBU): 28 dBu
- PHONES OUT IMPEDANCE (OHM): 150 ohm
- PHONES OUT LEVEL (DBM): 10 dBm
Compressors
- RCF COMPRESSORS: n°6 Single Control Compressors on Channels 1 to 6
EQ
- INPUT CHANNELS EQ: 1 Semi Parametric / 2 Shelving
- DESCRIPTION: High: +/-15 dB @ 10 kHz Shelving Mid: +/-15 dB @ Freq. sel. from 100Hz to 8kHz – Bell Low: +/-15 dB @ 100 Hz Shelving
Auxiliary sends
- AUX: 2 PRE / 1 PRE/POST
- FX POST: 1
Internal Effects
- SEND EFFECTS: 1
USB audio
- TYPE: B
- PLAY TRK: 2
- REC TRK: 2
- SUPPORTED SAMPLE RATE (KHZ): 44.1, 48.0 kHz
Other features
- FOOTSWITCH: Yes
Standard compliance
- CE MARKING: Yes
Physical specifications
- CABINET/CASE MATERIAL: Metal
- COLOR: Black
Siz
- DEPTH: 406 mm / 15.98 inches
- HEIGHT: 107 mm / 4.21 inches
- WEIGHT: 9.5 kg / 20.94 lbs
- WIDTH: 720 mm / 28.35 inches
Shipping informations
- PACKAGE DEPTH: 524 mm / 20.63 inches
- PACKAGE HEIGHT: 201 mm / 7.91 inches
- PACKAGE WEIGHT: 12.5 kg / 27.56 lbs
- PACKAGE WIDTH: 759 mm / 29.88 inches
