Description
Fader-free, all-in-one M 18 has an on-board WiFi access point with both external and internal antennas, enabling full wireless control from up to 5 tablets. It features a total of 18 analog inputs, 8 mic preamps, up to 19 simultaneous studio-grade effects and a full suite of plug-in algorithms and professional internal effects, including a high-quality stereo reverb and classic emulations of guitar and bass amplifiers.
The input EQs (Standard, Vintage and Smooth) enable a wide range of sounds and a flexible sound-sculpting environment. A Mastering processor on the main outputs allows a final fine-tuning of the overall sound. A USB port for the internal two-track player and recorder, MIDI ports and footswitch input provide maximum flexibility.
- 18 analog input channels, 8 mic preamps and 10 Line inputs including 2 HiZ switchable inputs
- Three internal FX: Reverb, Delay, Modulation
- 19 simultaneous studio-grade effects, including Guitar & Bass emulations developed by Overloud
- MixRemote app ensuring a comprehensive control
- Valve warmer, Xciter, Maximizer and Stereo Graphic EQ on Main Mix
- 1 stereo main out and 6 aux outputs
- USB port for the internal four-track player and two-track recorder
- MIDI IN and OUT ports
- 1 dual footswitch connector
- Internal power supply
- FREQUENCY RESPONSE: 20 Hz ÷ 20000 kHz
- POWER SUPPLY: Internal
- VOLTAGE REQUIREMENTS: 90 V – 240 V
- POWER CONSUMPTION (W): 40 W
- PROCESSING CHANNELS: 20
- SIGNAL PROCESSING: 32 Bit Floating Point
- A/D-D/A CONVERSION: 24 Bit @ 48.0 kHz
- DYNAMIC RANGE: 114
- DUAL BAND: Yes
- EXTERNAL ANTENNAS: 1
- IEEE802.11 B/G STANDARD (GHZ): 2.4 / 5.0 – US version: 2.4 GHz only
- INTERNAL ANTENNAS: 2
- INTERNAL ACCESS POINT: Yes
- A/D DYNAMIC RANGE (DB): 114 dB
- GAIN RANGE: 0 dB ÷ 60 dB
- GAIN SELECTION: -10 dB ÷ 4 dB
- HI-Z LINE INPUTS IMPEDANCE (MOHM): 1 Mohm
- HI-Z LINE INPUTS: 2
- MIC INPUTS IMPEDANCE (KOHM): 1 kohm
- LINE: 10
- LINE INPUT IMPEDANCE (KOHM): 10 kohm
- LOW CUT: 10 Hz ÷ 500 dB
- MIC: 8
- PHANTOM POWER +48V: Yes
- MAIN MIX: 2
- FX SEND: 3
- AUX SEND: 6
- AUX OUTPUT: 6
- PHONES: 1
- MAIN OUT IMPEDANCE (OHM): 50 ohm
- MAIN OUT LEVEL (DBU): 21 dBu
- AUX OUT IMPEDANCE (OHM): 50 ohm
- AUX OUT LEVEL (DBU): 21 dBu
- PHONES OUT IMPEDANCE (OHM): 40 ohm
- PHONES OUT LEVEL (DBM): 35 dBm
- D/A DYNAMIC RANGE (DB): 114 dB
- RCF GATES: “Gates present on all input channel”
- RCF COMPRESSORS: Compressor on each input channel
- INPUT CHANNELS EQ: 2 Full Parametric / 2 Semi Parametric / 2 Shelving / 4 Generic
- AUX OUTPUT EQ: 2 Full Parametric / 2 Shelving
- AUX: 4 PRE / 2 PRE/POST
- FX POST: 3
- SEND EFFECTS: 3
- MULTIFX INSERT EFFECTS: 16
- MAIN OUT PROCESSORS: 4.00
- MAIN OUT TYPE: “Valve Warmer, Xciter, Maximizer, 31 band Graphic EQ present on MAIN MIX”
- TYPE: A
- PLAY TRK: 2
- REC TRK: 2
- SUPPORTED SAMPLE RATE (KHZ): 48.0
- SUPPORTED PLAY FORMATS: MP3, WAV, AIFF
- COMPRESSED FILE FORMAT PLAY (UP TO) (KBPS): 320 Kbps
- SUPPORTED REC FORMAT: WAV
- FOOTSWITCH: Yes
- MIDI IN: Yes
- MIDI OUT: Yes
- LAN PORT: Yes
- CE MARKING: Yes
- CABINET/CASE MATERIAL: ABS
- COLOR: Black
- RACK MOUNTING: 2U , Optional rack mounting accessory required
- DEPTH: 180 mm / 7.09 inches
- HEIGHT: 88 mm / 3.46 inches
- WEIGHT: 2.5 kg / 5.51 lbs
- WIDTH: 340 mm / 13.39 inches
- PACKAGE DEPTH: 132 mm / 5.2 inches
- PACKAGE HEIGHT: 378 mm / 14.88 inches
- PACKAGE WEIGHT: 3.4 kg / 7.5 lbs
- PACKAGE WIDTH: 253 mm / 9.96 inches
